Ku-Band Block Up Converters

This smallest and lightest 8W and 10W L-To Ku-Band Block Up Converter is based on GaN technology. Double L.O. and field- Exchangeable connector make unit universal for any Ku-Band application. Incomparable low power consumption allowes the BUC to be powered by iDirect and similar modems. Internal 10MHz reference option enables using the BUC with the modems without 10MHz reference.


  • Output frequency 13.75-14.50 GHz
  • Based on GaN technology which enables high efficiency, low energy consumption and high reliability
  • Double - L.O. (switchable 12.80 and 13.05 GHz)
  • Incomparable low power consumption (45W max)- can be powered by iDirect or similar modems
  • Extreme P-Out GaN linearity
  • Digital temperature compensation
  • L.O. lock and amplifier LEDs
  • Field-exchangeable (F/N) IF connector
  • Internal 10MHz high stability reference (optional)
  • RoHS compliant
