MODEL 4.7M PRIME FOCUS ANTENNA

Model 4.7m Prime Focus Antenna

• Bolt-together, all-aluminum reflector with self-aligning, fully interchangeable components • Designed for 1 to 15 GHz operation, meeting FCC 25.209 and ITURS- 580 regulations • Galvanized steel elevation over azimuth pedestal with jackscrews or struts • Survives 125 mph winds in any position The General Dynamics SATCOM Technologies 4.7-meter antenna delivers exceptional performance for receive only and transmit/receive applications for L, C and Ku-band frequencies. This antenna offers a reflector that incorporates precision-formed panels and contoured radials that ensure ease of installation. It features a prime focus feed design which results in high gain and low noise temperature, with excellent rejection of noise and microwave interference. The reflector is supported by a galvanized pedestal that provides the required stiffness for pointing and tracking accuracy. The pedestals are designed for full orbital arc coverage and are readily adaptable to ground or rooftop installations. The electrical performance is compliant with FCC 25.209 regulations and ITU-RS-580 sidelobe specifications. All configurations meet SATCOM Technologies’ own typeapproved quality assurance and performance guarantee. Options • L, C and Ku-band feed configurations • C/Ku receive-only feed systems • Fixed or motorizable pedestals • Antenna control system with tracking • Reflector and feed deicing systems • Load frame or non-penetrating mounts • Packing for sea and air transport
