SATELLITE SIGNAL LEVEL METER MODULE FOR NORTH AMERICAN DBS & BROADCAST TVRO

Satellite Signal Level Meter Module for North American DBS & Broadcast TVROThis is a test module to be used with the XR3 Modular Test Instrument.

FEATURES
• Compatible with XR-3 Modular Test Instrument
• Friendly user interface
• Satellite ID by "align-to-lock" or "automatic scan“
• ID multi-lock algorithm eliminates false positives
• Powers LNBs and multi-switches
• Use for L, C, X, Ku, or Ka band applications
• High sensitivity assures alignment optimization
• Geo-sensitive "Field Guide" software database stores all compatible satellites and transponders per global region
• Program and store up to 256 custom transponders
• Controls multi-LNBs/switches with 22kHz DiSEqC tone
• Manually tune to custom transponders using front panel keypad
• Audible tone for signal lock or peak
• Store measurements for Proof-of-performance reporting
• "Limit Scan" Pass/Fail for key transponders
• Displays antenna settings (AZ / EL / Skew) based on user's postal code or latitude and longitude coordinates
• Field replaceable type F barrel connectors
• Fast system boot-up time in less than 5 seconds

This item must be used with the XR3 Modular Test Instrument.
